Barton High Load Wire Rope Block Fixed Eye 91301

Here is a range of high strength blocks designed for use with wire ropes or in exceptionally rugged conditions.
Cheeks are manufactured from Marine Grade Aluminium 'Spectro' grey anodised UV resistance and durability.
Sheaves are precision turned aluminium bar silver anodised and running on a stainless centre bush.
Reinforcing plates, rivets and shackles are all from 316 stainless steel.
Available in fixed eye or swivel head.

NOTE: To ensure maximum strength and load capabilities fastenings must pass through hollow centre rivets or cheek blocks.

Sheave Diameter ~ 45mm

Sheave Width ~ 8mm

Rope Diameter ~ 5mm

Wire Diameter ~ 5mm

Breaking Load ~ 1300kg

Safe Working Load ~ 650kg

Weight ~ 163grams
