Aquafax Ball Valve Full Flow 1 1/4 inch BSP

Good quality full flow ball valves at competitive prices. Suitable for industrial pneumatic & hydraulic installations including gasoline fuel oils kerosene petrol and diesel. Ideal for hot and cold water different oils and compressed air.

Minimum 100000 operation design
90 degree movement by either lever or tee handle
Materials:
Body: Nickel plated brass CW 617N
Ball: Hard chrome plated brass CW 617N
Stem: Brass CW 614N
Seal: Pure Teflon PTFE
O Rings: Viton / NBR
Lever Handle: Red coated zinc plated steel Fe P04
Working Temperatures:
minus 20 Degrees C 150 Degrees C in absence of steam
WARNING the formation of ice can severely damage valves and piping
Technical Specification
BSP Parallel Thread ISO 228 equivalent to DIN EN ISO 228 & BS EN ISO 228
Bar* Pressure Atmosphere Kg/cm Cubed
PSI* LBS Working Pressure.
